UA973 Car Multimeter

5999 digital multimeter for measuring capacitance, resistance, temperature, TRMS, 10A AC/DC current, 600V DC/AC voltage, 4CYL/6CYL/8CYL for car manufacturer

UA973 Car multimeter


Key Specifications/Special Features:

5999 digital multimeter for measuring capacitance, resistance, temperature, TRMS, 20A AC/DC current, 600V DC/AC voltage, 4CYL/6CYL/8CYL for car manufacturer

  •  General characteristics:
    1. Display: LCD
    2. Maximum display: 5999, 3 5/6 automatic polarity display and unit display
    3. Measurement methods: double integral A/D conversion
    4. Sampling rate: 3 times /second
    5. Over range display: OL
    6. Low voltage display: display low voltage symbols
    7. Working environment: 0 to 40°C, relative humidity <80%
    8. Storage environment: -10 to 50°C, relative humidity <80%
    9. Battery: 3V (2*1.5V AAA type) not included here.
    10. Volume size: 150 x 74 x 43 mm
    11. Weight: about 233g (including battery)

Basic Function
DC Voltage200MV200MV
2V2V
20V20V
200V200V
600V600V
AC Voltage200V200MV/2V/20V200V
600V600V
DC Current2mAx
20mAx
200mA2A
10A20A
AC Current600uA/6000uAx
60mA/600mAx
6A2A
10A 20A

200Ω200Ω

2kΩ2kΩ
Resistance20kΩ20kΩ

200kΩ200kΩ

2MΩ2MΩ
Temperature-20℃-400℃-50℃-1000℃
400℃-1000℃-58℉-1832℉
Special FeatureCapacitance10nF/100nF/1uF/10uF/100uF/1000uF/10mF/100mF
Frequency100Hz/1000Hz/10kHz/100kHz/1mHz/10mHz
Continuity   Testv
True   RMSx
Engineer   Dwell:4GYL/6GYL/8GYLv
Engineer   Rev:4GYL/6GYL/8GYLv
Transistor
Low   Battery Display
Data   Hold
Self-recovered   safety
Filter   Protection
Auto   Power Off
Back   Light
Display5999
Operating   Mode
CATIII   600V
Battery
Size
Weight
Accessory
